Planet ISW 804PT M12 10/100 PoE Switch
Teknik Özellikler
| Physical Port |
| 8-port 10/100Mbps M12 Connector with IP67 protection |
| 4-port IEEE 802.3af PoE Ports (Port 5 to port 8) |
| Layer 2 Features |
| Supports auto negotiation and 10/100Mbps half / full duplex mode |
| High performance Store and Forward architecture, runt/CRC filtering eliminates erroneous packets to optimize the network bandwidth |
| Prevents packet loss with back pressure (half-duplex) and IEEE 802.3x pause frame flow control (full-duplex) |
| Backplane (Switching Fabric): 1.6Gbps |
| Integrated address look-up engine, supports 2K absolute MAC addresses |
| Automatic address learning and address aging |
| CSMA/CD Protocol |
| Power over Ethernet |
| 4 Ports compliant with IEEE 802.3af Power over Ethernet / PSE Standard |
| Supports PoE Power up to 15.4 watts for each PoE port |
| Auto-detects powered device (PD) |
| Circuit protection prevents power interference between ports |
| Remote power feeding up to 100m |
| Industrial Case / Installation |
| IP67 aluminum metal case protection |
| DIN rail and wall mount design |
| Waterproof / dustproof design |
| 48V DC, redundant power with polarity reverse protect function and connective removable terminal block for master and slave power |
| Supports EFT 6000VDC protection for power line |
| Supports ESD 6000 VDC Ethernet protection |
| -40 to 75 degrees C operating temperature |
Teknik Kısa
PoE : PoE
Port Hızı : 100 Mbps
Yönetilebilirlik : Yönetilebilir Layer 2
PoE : Hibrid
PoE Port Sayısı :
4 Port
4 Port PoE Güç Bütçesi : 50-130 Watt
Montaj Tipi : Wall Mount
Çalışma Mesafesi : 100Mt.
