ONV ONV-H2108PL PoE Switch

Özellikler

Unmanaged PoE switch with 8*10/100M RJ45 ports and 2*10/100M uplink RJ45 ports.
Port 1-8 support DC24V PoE output.
Turn on the function switch(EXTEND), which can realize port 1-8 VLAN isolation and 10M/250m transmission.

Teknik Özellikler

Model	ONV-H2064PL	ONV-H2108PL
Interface Characteristics
Fixed Port	4*10/100Base-TX PoE ports (Data/Power)	8*10/100Base-TX PoE ports (Data/Power)
	2*10/100Base-TX uplink RJ45 Ports (Data)	2*10/100Base-TX uplink RJ45 Ports (Data)
Ethernet Port	10/100Base-T(X) auto-sensing, full/half duplex MDI/MDI-X self-adaption
Functional Switch (EXTEND)	Port 1-4 support port VLAN and 10M/250m transmission	Port 1-8support port VLAN and 10M/250m transmission
	Note: When the switch status changes, the PoE switch must be restarted for the switch function to take effect.
Twisted Pair Transmission	10BASE-TX : Cat5 or later UTP(≤250 meter)
	100BASE-TX: Cat5 or later UTP(≤100 meter)
Chip Parameter
Network Protocol	IEEE802.3 10BASE-T, IEEE802.3i 10Base-T
	IEEE802.3u 100Base-TX, IEEE802.3x
Forwarding Mode	Store and Forward(Full Wire Speed)
Switching Capacity	1.6Gbps (Non-blocking)	2Gbps (Non-blocking)
Forwarding Rate@64byte	0.89Mpps	1.488Mpps
MAC	1K	2K
Buffer Memory	768K	1.25M
Jumbo Frame	1536byte
LED Indicator	Power: PWR (Green), Network:L/A (Green), Function switch: EXTEND (Green)
PoE & Power
PoE Port	Port 1-4 can support 24V PoE	Port 1-8 can support 24V PoE
Power Supply Pin	Default 4/5 (+), 7/8 (-)
Single-port Max/AVG Power	24W/15W
Total PWR / Input Voltage	65W /(AC100-240V)	120W/ (AC100-240V)
Power Consumption	Standby<3W, Full load<60W	Standby<5W, Full load<120W
Power Supply	Built-in power supply, AC100~240V 50-60Hz 1A	Built-in power supply, AC100~240V 50-60Hz 2.2A
Physical Parameter
Operation TEMP / Humidity	-20~+55°C, 5%~90% RH Non condensing
Storage TEMP / Humidity	-40~+75°C, 5%~95% RH Non condensing
Dimension (LWH)	14211540mm	19513040mm
Net /Gross Weight	<0.6kg / <1kg	<0.8kg / <1.2kg
Installation	Desktop,Wall-mounted, Rack mounted
Certification & Warranty
Lightning Protection / Protection Level	Lightning protection: 4KV 8/20us; Protection level: IP30
Certification	CCC, CE mark, commercial, CE/LVD EN60950, FCC Part 15 Class B RoHS
Warranty	1 year, lifelong maintenance
