ONV ONV-POE33020PFM PoE Switch

Özellikler

L2+ managed PoE fiber switch with 16* 10/100/1000M RJ45 ports and 4*100/1000M SFP fiber slot ports, Port 1-16 can support IEEE802.3af/at PoE standard, Built-in 250W power supply.

Teknik Özellikler

Model	ONV-POE33020PFM
Interface Characteristics
Fixed Port	16*10/100/1000Base-T PoE ports (Data/Power)
	4*100/1000Base-X uplink SFP slot ports (Data)
	1 * RS232 console port(115200,N,8,1)
Ethernet Port	Port 1-16 can support 10/100/1000Base-T(X) auto-sensing,Full/half duplex MDI/MDI-X self-adaption
Twisted Pair Transmission	10BASE-T: Cat3,4,5 UTP(≤100 meter)
	100BASE-TX: Cat5 or later UTP(≤100 meter)
	1000BASE-T: Cat5e or later UTP(≤100 meter)
SFP Slot Port	Gigabit SFP optical fiber interface, default matching optical modules (optional order single-mode / multi-mode, single fiber / dual fiber optical module. LC)
Optical Cable	Multi mode: 850nm 0 ~ 550M, Single mode: 1310nm 0 ~ 40KM, 1550nm 0 ~ 120KM.
Chip Parameter
Network Management Type	L2+
Network Protocol	IEEE802.3 10BASE-T, IEEE802.3i 10Base-T
	IEEE802.3u 100Base-TX, IEEE802.3ab 1000Base-T
	IEEE802.3z 1000Base-X, IEEE802.3x
Forwarding Mode	Store and Forward(Full Wire Speed)
Switching Capacity	192Gbps
Forwarding Rate@64byte	29.76Mpps
MAC	8K
Buffer Memory	4.1M
Jumbo Frame	10K
CPU(Hz)	500M
DRAM	1G
Flash	256M
LED Indicator	Power:PWR (yellow), system :SYS (yellow), network: Link(yellow), POE: PoE (green), Fiber port: L/A(green)
Reset Switch	Yes, One-button factory reset
PoE & Power Supply
PoE Port	Port 1 to 16 IEEE802.3af/at @ POE
PoE Management	PoE working status
	Delay start of power supply
	PoE output priority configuration
	Total power limit of PoE power supply
	Scheduling of PoE operation and time
	PoE output power allocation, off& af &at
Power Supply Pin	Default 1/2 (+), 3/6 (-)
Max Power Per Port	30W; IEEE802.3af/at
Total PWR / Input Voltage	250W (AC100-240V)
Power Consumption	Standby<16W, Full load<240W
Power Supply	Built-in power supply, AC 100~240V 50-60Hz 4.1A
Physical Parameter
Operation TEMP / Humidity	-20~+55°C;5%~90% RH Non condensing
Storage TEMP / Humidity	-40~+75°C;5%~95% RH Non condensing
Dimension (LWH)	44029044.5mm
Net /Gross Weight	<4.0kg / <4.5kg
Installation	Desktop, 19 inch 1U cabinet
Certification & Warranty
Lightning protection / protection level	Lightning protection: 6KV 8/20us; Protection level: IP30
Certification	CCC;CE mark, commercial; CE/LVD EN60950;FCC Part 15 Class B; RoHS
Warranty	3 years, lifelong maintenance.
Network Management Features
Interface	IEEE802.3X (Full-duplex)
	Port temperature protection setting
	Port green Ethernet Energy-saving setting
	Broadcast storm control based on port speed
	The speed limit of the message flow in the access port. The minimum particle size is 64Kbps.
Layer 3 Features	L2+ Network management, IPV4 management
Layer 3 Features	L3 soft routing forwarding, Static route, Default route @ 128 pcs, APR @ 1024 pcs
VLAN	4K VLAN based on port, IEEE802.1q
	Port configuration of Access, Trunk, Hybrid
	VLAN based on MAC, VLAN based on the protocol, QinQ configuration
Port Aggregation	LACP, Static aggregation
Port Aggregation	Max 10 aggregation groups and 8 ports per group.
Spanning Tree	STP (IEEE802.1d),RSTP (IEEE802.1w),MSTP (IEEE802.1s)
Multicast	IGMP Snooping v1/v2, Max 1024 multicast groups, Fast log out
Multicast	MLD Snooping v1/v2,Multicast VLAN
Port Mirroring	Bidirectional data mirroring based on port
QoS	Diff-Serv QoS,Priority Mark/Remark
	8*Output queues of each port
	802.1p/DSCP priority mapping
	Queue Scheduling Algorithm (SP, WRR, SP+WRR)
	Flow-based Packet Filtering
	Flow-based Redirection
	Flow-based Rate Limiting
ACL	L2 to L4 packet filtering, matching first 80 bytes message. Provide ACL based on MAC, Destination MAC address, IP Source, Destination IP, IP Protocol Type, TCP/UDP Port, TCP/UDP Port Range, and VLAN, etc. Port-based Issuing ACL.
ACL	ACL based on port and VLAN
Security	User hierarchical management and password protection
	SSH 2.0,SSL,Port isolation,ARP message speed limit
	Broadcast storm control,Backup for host datum
	IEEE802.1X & MAC address authentication
	Mac black holes,IP source protection
	AAA & RADIUS,MAC learning limit
	ARP inspection,Anti-DoS attack
	IP-MAC-VLAN-Port binding
DHCP	DHCP Client,DHCP Snooping,DHCP Server,DHCP Relay
Management	Console/AUX Modem/Telnet/SSH2.0 CLI
	Web Management (HTTPS)
	Download & Management on FTP, TFTP, Xmodem, SFTP,SNMP V1/V2C/V3
	One-key recovery
	NTP,System work log,Ping Test
	Cable Diagnose,LLDP
	CPU instant utilization status view
	ONV NMS -Network Management System Platform (LLDP+SNMP)
System	Web browser: Mozilla Firefox 2.5 or higher, Google browser chrome V42 or higher, Microsoft Internet Explorer10 or later;
	Category 5 Ethernet network cable
	TCP/IP, network adapter, and network operating system (such as Microsoft Windows, Linux, or Mac OS X) installed on each computer in a network
