Planet MGS-6320-2T6S2X Layer 3 Ethernet Switch
Teknik Özellikler
| Hardware Specifications | |
| Copper Ports | 2 100/1000BASE-T RJ45 auto-MDI/MDI-X ports |
| (Port 1 and port 2) | |
| SFP Ports | 2 1000BASE-SX/LX/BX SFP ports (Port 3 and port 4) |
| Compatible with 100BASE-FX SFP. | |
| 4 100/1000/2500BASE-X SFP ports (Port 5 and port 8) | |
| SFP+ Ports | 2 1000/2500/10GBASE-X SFP ports (Port 9 and port 10) |
| Console | 1 x RJ45 serial port (115200, 8, N, 1) |
| Reset Button | < 5 sec: System reboot |
| > 5 sec: Factory default | |
| RAM | 512Mbytes |
| Flash Memory | 64Mbytes |
| Dimensions (W x D x H) | 330 x 153 x 44 mm, 1U high |
| Weight | 1486g |
| Power Requirements | AC 100~240V, 50/60Hz 1A |
| 24V DC @ 1.5A, Range: 24V ~ 57V DC | |
| Power Consumption | Max. 16.2 watts/55.2 BTU (AC input) |
| Max. 17.6 watts/60 BTU (DC input) | |
| Alarm | One relay output for power failure. Alarm Relay current carry ability: 1A @ DC 24V |
| DI/DO |
2 Digital Input (DI): Level 0: -24V~2.1V (±0.1V)
|
|
Level 1: 2.1V~24V (±0.1V)
|
|
|
Input Load to 24V DC, 10mA max.
|
|
| 2 Digital Output (DO): Open collector to 24VDC, 100mA max. | |
| ESD Protection | 6KV DC |
| LED | System: |
|
PWR (Green), DC 1 (Green), DC 2 (Green)
|
|
|
DI/DO (Red), Alarm (Red), Ring (Green), Ring Owner (Green)
|
|
| Gigabit RJ45 Ports (Ports 1 to 2) | |
|
100 LNK/ACT (Amber)
|
|
|
1G LNK/ACT (Green)
|
|
| Gigabit SFP Ports (Ports 3 to 4) | |
|
100 LNK/ACT (Amber)
|
|
|
1G LNK/ACT (Green)
|
|
| Gigabit SFP Ports (Ports 5 to 8) | |
|
100 LNK/ACT (Amber)
|
|
|
1G/2.5G LNK/ACT (Green)
|
|
| 10 Gigabit SFP Ports (Ports 9 to 10) | |
|
10G LNK/ACT (Amber)
|
|
|
1G/2.5G LNK/ACT (Green)
|
|
| Switching Specifications | |
| Switch Architecture | Store-and-Forward |
| Switch Fabric | 68Gbps/non-blocking |
| Throughput | 50.59Mpps @ 64Bytes packet |
| Address Table | 8K entries, automatic source address learning and aging |
| RAM | 512Mbytes |
| Flash | 64Mbytes |
| Flow Control | IEEE 802.3x pause frame for full duplex |
| Back pressure for half duplex | |
| Jumbo Frame | 10KB |
| Layer 3 Functions | |
| IP Interfaces | Max. 32 VLAN interfaces |
| Routing Table | Max. 32 static route entries |
| Max. 1K routing table entries | |
| Routing Protocols | IPv4 RIPv1/v2 |
| IPv4 OSPFv2 | |
| IPv6 OSPFv3 | |
| IPv4 hardware static routing | |
| IPv6 hardware static routing | |
| Layer 2 Functions | |
| Port Configuration | Port disable/enable |
| Auto-negotiation 10/100/1000Mbps full and half duplex mode selection | |
| Flow Control disable/enable | |
| Port link capability control | |
| Port Status | Display each port’s speed duplex mode, link status, flow control status, auto negotiation status, trunk status |
| Port Mirroring | TX/RX/Both |
| Many-to-1 monitor | |
| Supports up to 5 sessions | |
| VLAN | IEEE 802.1Q tag-based VLAN, |
| IEEE 802.1ad Q-in-Q tunneling | |
| Private VLAN Edge (PVE) | |
| MAC-based VLAN | |
| Protocol-based VLAN | |
| Voice VLAN | |
| MVR (Multicast VLAN Registration) | |
| GVRP | |
| Up to 4K VLAN groups, out of 4094 VLAN IDs | |
| Link Aggregation | IEEE 802.3ad LACP/Static Trunk |
| Supports 5 trunk groups with 10 ports per trunk group | |
| Spanning Tree Protocol | IEEE 802.1D Spanning Tree Protocol |
| IEEE 802.1w Rapid Spanning Tree Protocol | |
| IEEE 802.1s Multiple Spanning Tree Protocol | |
| QoS | Traffic classification based, strict priority and WRR |
| 8-level priority for switching | |
| - Port number | |
| - 802.1p priority | |
| - 802.1Q VLAN tag | |
| - DSCP/TOS field in IP packet | |
| Ring | Supports ERPS, and complies with ITU-T G.8032 |
| IGMP Snooping | IGMP (v1/v2/v3) Snooping, up to 255 multicast groups |
| IGMP Querier mode support | |
| MLD Snooping | MLD (v1/v2) Snooping, up to 255 multicast groups |
| MLD Querier mode support | |
| Bandwidth Control | Per port bandwidth control |
| Ingress: 500Kb~13128Mbps | |
| Egress: 500Kb~13128Mbps | |
| Security Functions | |
| Access Control List | IP-based ACL/MAC-based ACL |
| ACL based on: | |
| - MAC Address | |
| - IP Address | |
| - Ethertype | |
| - Protocol Type | |
| - VLAN ID | |
| - DSCP | |
| - 802.1p Priority | |
| Up to 512 entries | |
| Security | Port security |
| IP source guard, up to 512 entries | |
| Dynamic ARP inspection, up to 1K entries | |
| Command line authority control based on user level | |
| Static MAC address, up to 64 entries | |
| AAA | RADIUS client |
| TACACS+ client | |
| Network Access Control | IEEE 802.1x port-based network access control |
| MAC-based authentication | |
| Local/RADIUS authentication | |
| Switch Management Functions | |
| Basic Management Interfaces | Console; Telnet; Web Browser; SNMP v1, v2c |
| Secure Management Interfaces | SSHv2, TLS v1.2, SNMP v3 |
| System Management | Firmware upgrade by HTTP protocol through Ethernet network |
| Configuration upload/download through HTTP | |
| Remote Syslog | |
| System log | |
| LLDP protocol | |
| NTP | |
| PLANET Smart Discovery Utility | |
| PLANET NMS system and CloudViewer | |
| Event Management | Remote Syslog |
| Local System log | |
| SMTP | |
| SNMP MIBs | SNMP MIBs |
| RFC 1213 MIB-II | |
| RFC 2863 IF-MIB | |
| RFC 1643 Ethernet MIB | |
| RFC 2863 Interface MIB | |
| RFC 2665 Ether-Like MIB | |
| RFC 2737 Entity MIB | |
| RFC 2819 RMON MIB (Groups 1, 2, 3 and 9) | |
| RFC 2618 RADIUS Client MIB | |
| RFC 3411 SNMP-Frameworks-MIB | |
| IEEE 802.1X PAE | |
| LLDP | |
| MAU-MIB | |
| Standards Conformance | |
| Regulatory Compliance | FCC Part 15 Class A, CE |
| Standards Compliance | IEEE802.3 10BASE-T |
| IEEE802.3u 100BASE-TX | |
| IEEE802.3z 1000BASE-SX/LX | |
| IEEE 802.3ab 1000BASE-T | |
| IEEE 802.3bz 2.5GBASE-X | |
| IEEE 802.3ae 10Gb/s Ethernet | |
| IEEE802.3x flow control and back pressure | |
| IEEE802.3ad port trunk with LACP | |
| IEEE802.1D Spanning Tree Protocol | |
| IEEE802.1w Rapid Spanning Tree Protocol | |
| IEEE 802.1s Multiple Spanning Tree Protocol | |
| IEEE802.1p Class of Service | |
| IEEE802.1Q VLAN tagging | |
| IEEE 802.1x Port Authentication Network Control | |
| IEEE 802.1ab LLDP | |
| RFC 768 UDP | |
| RFC 793 TFTP | |
| RFC 791 IP | |
| RFC 792 ICMP | |
| RFC 2068 HTTP | |
| RFC 1112 IGMP v1 | |
| RFC 2236 IGMP v2 | |
| RFC 3376 IGMP v3 | |
| RFC 2710 MLD v1 | |
| RFC 3810 MLD v2 | |
| RFC 2328 OSPF v2 | |
| RFC 2453 RIP v2 | |
| Environment | |
| Operating | Temperature: -10 ~ 60 degrees C for DC power input |
| 0 ~ 50 degrees C for AC power input | |
| Relative Humidity: 5 ~ 95% (non-condensing) | |
| Storage | Temperature: -10 ~ 70 degrees C |
| Relative Humidity: 5 ~ 95% (non-condensing) | |
