| Hardware Specifications |
| Ethernet Ports | 8 1000BASE-T RJ45 auto-MDI/MDI-X ports |
| SFP+ Slots | 12 10GBASE-SR/LR SFP+ interface |
| Compatible with 1000BASE-SX/LX/BX SFP transceiver |
| Console | 1 x RJ45-to-DB9 serial port (9600, 8, N, 1) |
| Reset Button | Reset to factory default |
| Switch Architecture | Store-and-forward |
| Switch Fabric | 256Gbps/non-blocking |
| Switch Throughput | 180Mpps |
| Address Table | 32K MAC address table with auto learning function |
| Shared Data Buffer | 3MB |
| Flow Control | Back pressure for half duplex |
| IEEE 802.3x pause frame for full duplex |
| Jumbo Frame | 9KB |
| LED | System: |
| PWR, SYS |
| Ports: |
| 10/100/1000T RJ45 Port: LNK/ACT |
| 1/10G SFP+ Slot: LNK/ACT |
| Dimensions (W x D x H) | 442.5 x 315 x 44 mm, 1U height |
| Weight | 4178g |
| Power Consumption | 55 watts/187.66 BTU (maximum) |
| Power Requirements | AC 100~240V, 50/60Hz |
| Fan | 2 |
| Management Function |
| System Configuration | Console, Telnet, SSH, Web browser, SNMP v1, v2c and v3 |
| Management | Supports both IPv4 and IPv6 addressing |
| Supports the user IP security inspection for IPv4/IPv6 SNMP |
| Supports MIB and TRAP |
| Supports IPv4/IPv6 TFTP |
| Supports IPv4/IPv6 NTP |
| Supports RMON 1, 2, 3, 9 groups |
| Supports the RADIUS authentication for IPv4/IPv6 Telnet user name and password |
| Supports IPv4/IPv6 SSH |
| The right configuration for users to adopt RADIUS server’s shell management |
| Supports CLI, console, Telnet |
| Supports SNMPv1, v2c and v3 |
| Supports Security IP safety net management function: avoid unlawful landing at non-restrictive area |
| Supports Syslog server for IPv4 and IPv6 |
| Supports TACACS+ |
| Layer 3 Function |
| Routing Protocol | Static routing, RIP and OSPF |
| Routing Table | 128 |
| DHCP | DHCP client |
| DHCP server, default-route |
| VRRP | Configure VRRP in interface VLAN; |
| VRRP priority; |
| VRRP standby; |
| VRRP track |
| Load Balancing | Use of equivalent routing, the correct load balancing function (by flow) |
| Layer 2 Function |
| Port Configuration | Port disable/enable |
| Auto-negotiation 10/100/1000Mbps full and half duplex mode selection |
| Flow control disable/enable |
| Bandwidth control on each port |
| Port loopback detect |
| Port Status | Display each port’s speed duplex mode, link status, flow control status and |
| | auto negotiation status |
| VLAN | 802.1Q tag-based VLAN, up to 4K VLAN entries |
| 802.1ad Q-in-Q (VLAN stacking) |
| GVRP for VLAN management |
| Private VLAN Edge (PVE) supported |
| Protocol-based VLAN |
| MAC-based VLAN |
| IP subnet VLAN |
| Bandwidth Control | TX/RX/both |
| Link Aggregation | IEEE 802.3ad LACP/static trunk |
| Supports 32 groups with 8 ports per trunk group |
| QoS | 8 priority queues on all switch ports |
| Supports strict priority and Weighted Round Robin (WRR) CoS policies |
| Traffic classification: |
| - IEEE 802.1p CoS/ToS |
| - IPv4/IPv6 DSCP |
| - Port-based WRR |
| Multicast | IGMP v1/v2/v3 snooping |
| Querier mode support |
| MLD v1/v2 snooping |
| Querier mode support |
| Multicast VLAN Register (MVR) |
| Access Control List | Supports Standard and Expanded ACL |
| IP-based ACL/MAC-based ACL |
| Time-based ACL |
| Up to 1K entries |
| Bandwidth Control | At least 64Kbps stream |
| Security | Port isolation |
| Supports IP + MAC + port binding |
| Identification and filtering of L2/L3/L4 based ACL |
| Defend against DOS or TCP attacks |
| Suppression of broadcast, multicast and unknown unicast packet |
| DHCP Snooping, DHCP Option 82 |
| Command line authority control based on user levels |
| Authentication | IEEE 802.1x port-based network access control |
| AAA authentication: TACACS+ and IPv4/IPv6 over RADIUS |
| SNMP MIBs | RFC 1213 MIB-II |
| RFC 1215 Internet Engineering Task Force |
| RFC 1271 RMON |
| RFC 1354 IP-Forwarding MIB |
| RFC 1493 Bridge MIB |
| RFC 1643 Ether-like MIB |
| RFC 1907 SNMPv2 |
| RFC 2011 IP/ICMP MIB |
| RFC 2012 TCP MIB |
| RFC 2013 UDP MIB |
| RFC 2096 IP forward MIB |
| RFC 2233 if MIB |
| RFC 2452 TCP6 MIB |
| RFC 2454 UDP6 MIB |
| RFC 2465 IPv6 MIB |
| RFC 2466 ICMP6 MIB |
| RFC 2573 SNMPv3 notification |
| RFC 2574 SNMPv3 VACM |
| RFC 2674 Bridge MIB Extensions |
| Standard Conformance |
| Regulatory Compliance | FCC Part 15 Class A, CE |
| Standards Compliance | IEEE 802.3 10BASE-T |
| IEEE 802.3u 100BASE-TX |
| IEEE 802.3z Gigabit 1000BASE-SX/LX |
| IEEE 802.3ab Gigabit 1000BASE-T |
| IEEE 802.3ae 10Gb/s Ethernet |
| IEEE 802.3x flow control and back pressure |
| IEEE 802.3ad port trunk with LACP |
| IEEE 802.1D Spanning Tree Protocol |
| IEEE 802.1w Rapid Spanning Tree Protocol |
| IEEE 802.1s Multiple Spanning Tree Protocol |
| IEEE 802.1p Class of Service |
| IEEE 802.1Q VLAN tagging |
| IEEE 802.1X port authentication network control |
| IEEE 802.1ab LLDP |
| RFC 768 UDP |
| RFC 793 TFTP |
| RFC 791 IP |
| RFC 792 ICMP |
| RFC 2068 HTTP |
| RFC 1112 IGMP v1 |
| RFC 2236 IGMP v2 |
| RFC 3376 IGMP v3 |
| RFC 2710 MLD v1 |
| FRC 3810 MLD v2 |
| RFC 2328 OSPF v2 |
| RFC 1058 RIP v1 |
| RFC 2453 RIP v2 |
| Environment |
| Operating | Temperature: 0 ~ 60 degrees C |
| Relative Humidity: 10 ~ 85% (non-condensing) |
| Storage | Temperature: -40 ~ 80 degrees C |
| Relative Humidity: 5 ~ 95% (non-condensing) |
| Ordering Information |
| XGS-6350-12X8TR | Layer 3 12-Port 10G SFP+ +8-Port 10/100/1000T Managed Switch with Dual 100~240V AC Redundant Power |
