| Model | DH-IPC-HDBW3101P | DH-IPC-HDBW3101N |
| Camera |
| Image Sensor | 1/3” 1.3Megapixel Aptina CMOS |
| Effective Pixels | 1280(H)x960(V) |
| Scanning System | Progressive |
| Electronic ShutterSpeed | Auto/Manual 1/3~1/10000 | Auto/Manual 1/4~1/10000 |
| Min. Illumination | 0.1lux/F1.4(color),0.005Lux/F1.4(B/W),0Lux(IR on) |
| S/N Ratio | >50dB |
| Video Output | 1 channel BNC(1.0Vp-p, 75Ω) |
| Camera Features |
| Max. IR LEDs Length | 20m |
| Day/Night | Auto(ICR)/Color/B/W |
| Backlight Compensation | Off/BLC/HLC/WDR(128dB) |
| White Balance | AUTO |
| Gain Control | Auto/Manual |
| Noise Reduction | 2D |
| Privacy Masking | Up to 4 areas |
| Lens |
| Focal Length | 2.8~12mm |
| Max Aperture | F1.4 |
| Focus Control | Manual |
| Angle of View | H: 92°(Wide)~27.2°(Tele) |
| Lens Type | Manual/Auto Iris (DC) |
| Mount Type | Board-in Type |
| Video |
| Compression | H.264 / MJPEG |
| Resolution | 1.3M(1280×960) / 720P(1280×720) / D1(704×576) / CIF(352×288) / | 1.3M(1280×960) / 720P(1280×720) / D1(704×480) / CIF(352×240) / |
| Frame Rate | Main Stream | 1.3M/720P(1 ~ 25/30fps) |
| Sub Stream | D1/CIF(1 ~ 25/30fps) |
| Bit Rate | H.264: 32K ~ 8192Kbps, MJPEG: 32K ~ 12288Kbps |
| Audio |
| Compression | G.711a / G.711u (64kbps)/ PCM(128kbps) |
| Interface | 1/1 channel In/Out |
| Network |
| Ethernet | RJ-45 (10/100Base-T) |
| Protocol | IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour |
| ONVIF | ONVIF Ver. 2.0 |
| Max. User Access | 10 users |
| Smart Phone | iPhone, iPad, Android, Windows Phone |
| Auxiliary Interface |
| Memory Slot | Micro SD, Max 32GB |
| Alarm | 1/1 channel In/Out |
| General |
| Power Supply | DC12V/AC24V, PoE(802.3af) |
| Power Consumption | <8W |
| Working Environment | -10°C~+60°C(-40~60°C optional), 10%~90% |
| Protection Level | IK10 & IP66 |
| Dimensions | Φ151x119mm |
| Weight | 1.05kg |
