| Image Sensor | 1/2.7" CMOS Omnivision, 2 Megapixel |
| Pixels - Total | 1920(H) x 1080(V) |
| Sensitivity | 0.2 lux @ F1.2 |
| Lens Drive Type | Auto iris (DC) |
| Lens Focal Length | 2.7 ~ 9 mm |
| Horizontal Viewing Angle | 103.5° ~ 34.3° |
| Motion Detection | On/ Off/ Sensitivity/ Area setting |
| Privacy zones | 2 zones, rectangle |
| White Balance | ATW, AWB, Manual |
| Shutter Speed | 1 sec to 1/10,000 sec |
| Camera ID | 20 character |
| Alarm Inputs | 1 |
| Alarm Outputs | 1 |
| Web Browser | MS Internet Explorer 6.0 (or higher) |
| Number of Clients | Up to 20 user |
| Video Compression | Dual stream: H.264+H.264, H.264+MJPEG, MJPEG+BNC or H.264+BNC |
| Video Resolution | 1920 x 1080 (12 fps), 1280 X 720 (25 fps) |
| Network Protocol | IPv4, IPv6, TCP/IP, UDP, RTP, RTSP, HTTP, HTTPS, ICMP, FTP, SMTP, DHCP, PPPoE, UPnP, IGMP, 802.1X and SNMP |
| SD memory | Micro SD/SDHC |
| Alarm Event | Alarm Input, Motion Detection or Schedule: Image transfer or alarm message by FTP, |
| Image transfer or alarm message by E-mail, |
| recording on SD-card, enable alarm output and send HTTP notification |
| Audio Compression | G.726 ADPCM, G.711 |
| LED Indicator | Power, link, active |
| Video Outputs | 1Vpp, BNC |
| Input/Output sockets | Video Out(BNC), Power(3-Pin Term), RJ-45, Micro SD Card Slot, |
| Alarm Terminal 4-Pin (Alarm In 2-Pin, Alarm Out 2-Pin), Audio (4-Pin) |
| Firmware Upgrade | Firmware upgrade by Web Browser |
| Configuration | Upload & Download configuration on remote PC |
| Protection Rating | IP66 |
| Operating Temperature | -10°C ~ +50°C |
| Humidity | 10 ~ 90% no condensation |
| Regulation | CE, FCC, RoHS Compliant |
| Supply Voltage | 12 VDC / 24 VAC / PoE IEEE 802.3af |
| Power Consumption | 5.5 W |
| Weight | 0.8 kg |
| Dimensions w*h*d | Ø 151 x 131 mm |
