| Thermal Camera |
| Array Format | 320 x 120 Native Resolution |
| 960 x 360 VividIR |
| Pixel Pitch | 12 µm |
| Maximum Frame Rate | 10 fps |
| Characteristics | Optical Characteristics |
| 2 x Lepton 3.5 Thermal Sensors |
| 57° Horizontal Field of View per Sensor |
| 90° Minimum Stitched Horizontal Field of View |
| f/1.1 Aperture |
< 50 mK Thermal Sensitivity
|
| Optical Camera | |
| Sensor Type | 1920 x 1080, 2.1 MP, 1/2.8" |
| Lens Type | 3mm, f/1.6, P-Iris with Auto Focus |
| Maximum Frame Rate | 30 fps |
| Aspect Ratio | 16:09 |
| White Balance | Automatic |
| Wide Dynamic Range | Yes |
| Day/Night Mode | Automatic |
| 940 nm LEDs |
| Power | PoE (802.af, Type 1, Class 3) |
| 12 VDC / 24 VAC |
| Power Consumption | < 5 W Typical
|
| | < 12 W with IR LEDs
|
| Analytics | |
| Analytics | Person and Vehicle Object Classification Line Crossing Detection |
| Object in Region |
| Rule Dependency/Multi-Rule Trigger |
| Event Notification via Relay Out |
| White Light LED Activation |
| ONVIF |
| API/Cloud Integration |
| General |
| Two-Way Audio | Yes |
| Relay Output | 1 x Relay Output |
| IP Rating | IP66 |
| NEMA Rating | NEMA 4X |
| Operating Conditions | -40 to 140°F / -40 to 60°C |
| Dimensions | Base: 6.1" / 156 mm |
| Protrusion with Sunshield: 6.7" / 171 mm |
| Weight | 3.7 lb / 1.7 kg |
| Packaging Info |
| Package Weight | 6.88 lb |
| Box Dimensions (LxWxH) | 15.2 x 10.8 x 6.8" |
