| Video |
| Imaging Device | 1/2.8" 2M CMOS |
| Effective Pixels | 1945(H)x1097(V) |
| Min. Illumination | Color : 0.27Lux (F2.0, 1/30sec) |
| B/W : 0.017Lux |
| Video Out | BNC(AHD / TVI / CVI / CVBS Selectable) |
| Lens |
| Focal Length (Zoom Ratio) | 2.8mm fixed focal |
| Max. Aperture Ratio | F2.0 |
| Angular Field of View | H: 113.7˚ / V: 61.5˚ / D: 134.5˚ |
| Min. Object Distance | 0.5m(1.64ft) |
| Focus Control | Manual |
| Pan / Tilt / Rotate |
| Pan / Tilt / Rotate Range | ˚~350˚ / 0˚~67˚ / 0˚~355˚ |
| Operational |
| Camera Title | Displayed up to 15 characters |
| Day & Night | Auto(ICR) |
| Backlight Compensation | BLC, HLC, WDR |
| Wide Dynamic Range | 120dB |
| Digital Noise Reduction | SSNRⅣ |
| Defog | Support |
| Motion Detection | 4ea |
| Privacy Masking | 8ea, rectangular zones |
| Gain Control | Low / Middle / High / Very High |
| White Balance | ATW / AWC / Manual / Indoor / Outdoor |
| Electronic Shutter Speed | 1 ~ 1/12,000sec |
| Video Rotation | H-Rev / V-Rev |
| Analytics | Motion detection |
| Coaxial Protocol | ACP(AHD Coax Protocol), TCP(TVI Coax Protocol), CCP(CVI Coax Protocol) |
| CVBS : Pelco-C(Coaxitron) |
| Video Transmission Distance | 500m(5C2V Coaxial Cable) |
| Network |
| Resolution | 1920 x 1080 |
| Max. Framerate | 30fps @1080p(N), 25fps @ 1080p(P) |
| Environmental |
| Operating Temperature / Humidity | -10°C ~ +55°C(+14°F ~ +131°F) / Less than 90% RH |
| Electrical |
| Input Voltage | 12VDC |
| Power Consumption | Max 3.6W |
| Mechanical |
| Color / Material | Ivory / Plastic |
| Product dimension / weight | Ø110 x 86mm(4.33 x 3.39"), 221g(0.49 lb) |
