| Camera |
| Image Sensor | 1/2.7 inch CMOS |
| Effective Pixels | 3840 (H)× 2160 (V), 4K |
| Scanning System | Progressive |
| Electronic Shutter Speed | PAL: 1/25s–1/100000s |
| NTSC: 1/30s–1/100000s |
| S/N Ratio | >65dB |
| Minimum Illumination | 0.03Lux/F2.0, 30IRE, 0Lux IR on |
| Fill Light Working Distance | 80m(262.5ft) |
| IR On/Off Control | Auto; manual |
| IR LED Number | 2 |
| Pan/Tilt/Rotation Range | "Pan: 0°–360° |
| Tilt: 0°–90° |
| Rotation: 0°–360°" |
| Lens |
| Lens Type | Fixed-focal |
| Mount Type | M12 |
| Focal Length | 3.6mm;6mm |
| Max. Aperture |
| Angle of View | 3.6mm: 104° x 87° x 47° (diagonal x horizontal x vertical) |
| 6mm:62.4° x54.7° x31.3°(diagonal x horizontal x vertical) |
| Iris Type | Fixed iris |
| Close Focus Distance | 3.6mm: 1.9 m (6.2 ft) |
| 6mm:3.6m(11.8ft) |
| DORI Distance | Lens | Detect | Observe | Recognize | Identify |
| 3.6mm | 106.7 m (350.1 ft) | 42.7 m (140.1 ft) | 21.3 m (69.9 ft) | 10.7 m (35.1 ft) |
| 6mm | 160m(524.9 ft) | 64 m (210.0ft) | 32 m (105.0ft) | 16 m (52.5ft) |
| Video |
| Frame Rate | CVI: 4K@25/30fps; 4K@15fps; 5M@20fps; 4M@25fps/30fps; |
| AHD: 4K@15fps; |
| TVI: 4K@15fps; |
| CVBS: 960H |
| Resolution | 4K (3840 × 2160); 5M (2592 × 1944); 4M (2560 × 1440); 960H (960 × 576/960 × 480) |
| Day/Night | Auto switch by ICR |
| BLC | BLC/HLC/WDR |
| WDR | DWDR |
| White Balance | Auto; manual |
| Gain Control | Auto; manual |
| Noise Reduction | 2D NR |
| Smart IR | Yes |
| Mirror | Off/On |
| Privacy Masking | Off/On (8 area, rectangle) |
| Certifications |
| Certifications | CE (EN55032, EN55024, EN50130-4,EN60950-1) |
| FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014) |
| UL (UL60950-1+CAN/CSA C22.2 No.60950-1) |
| Port |
| Video Output | Video output choices of CVI/TVI/AHD/CVBS by one BNC port |
| Power |
| Power Supply | 12V ±30% DC |
| Power Consumption | Max 6W (12V DC, IR on) |
| Environment |
| Operating Temperature | -40°C to +60°C (-40°F to 140°F);<95% (non-condensation) |
| Storage Temperature | -40°C to +60°C (-40°F to 140°F);<95% (non-condensation) |
| Protection Grade | IP67 |
| Structure |
| Casing | Metal front cover+plastic main body+metal bracket |
| Camera Dimensions | 240.7mm×90.7m×90.4mm (9.48”×3.57”×3.56”) |
| Net Weight | 0.42Kg (0.93lb) |
| Gross Weight | 0.62Kg (1.37lb) |
