| Camera |
| Pixel | 8 MP |
| Image Sensor | 4K CMOS |
| Max. Resolution | 3840 (H) × 2160 (V) |
| Scanning System | Progressive |
| Electronic Shutter Speed | PAL: 1/25 s–1/100000 s |
| NTSC: 1/30 s–1/100000 s |
| Min. Illumination | 0.01 lux@F1.5 (Color, 30 IRE) |
| 0.001 lux@F1.5 (B/W, 30 IRE) |
| 0 lux (Illuminator on) |
| S/N Ratio | >65 dB |
| Illumination Distance | 80 m (262.47 ft) |
| Illuminator On/Off Control | Auto/Manual |
| Illuminator Number | 4 (IR light) |
| Pan/Tilt/Rotation Range | Pan: 0°–360° |
| Tilt: 0°–90° |
| Rotation: 0°–360° |
| Lens |
| Lens Type | Motorized Vari-focal |
| Auto Focus | Yes |
| Lens Mount | φ14 |
| Focal Length | 2.7 mm–13.5 mm |
| Max. Aperture | F1.5 |
| Field of View | Horizontal: 114°–32° |
| Vertical: 58°–17° |
| Diagonal: 138°–36° |
| Iris Control | Fixed |
| Close Focus Distance | 0.8m |
| DORI Distance | Lens | Detect | Observe | Recognize | Identify |
| | W | 85.3 m (279.86 ft) | 34.1 m (111.88 ft) | 17.1 m(56.10 ft) | 8.5 m(27.89 ft) |
| | T | 280.0 m (918.64 ft) | 112.0 m (367.45 ft) | 56.0 m (183.73 ft) | 28.0 m(91.87 ft) |
| Video |
| Video Frame Rate | CVI: |
| PAL: 4K@15 fps; 5M@25 fps; 4M@25 fps; 1080p@25 fps |
| NTSC: 4K@15 fps; 5M@25 fps; 4M@30 fps; 1080p@30 fps |
| TVI: |
| PAL: 4K@15 fps |
| NTSC: 4K@15 fps |
| AHD: |
| PAL: 4K@15 fps |
| NTSC: 4K@15 fps |
| CVBS: |
| PAL: 960H |
| NTSC: 960H |
| Resolution | 4K (3840 x 2160); |
| 5M (2880 x 1620); |
| 4M (2560 x 1440); |
| 1080p (1920 x 1080); |
| 960H (960 x 576/960 x 480) |
| Day/Night | Auto(ICR)/Color/B/W |
| BLC | BLC; HLC; WDR; HLC-Pro |
| WDR | 120 dB |
| White Balance | Auto;Area white balance |
| Gain Control | Auto/Manual |
| Noise Reduction | 3D NR |
| Motion Detection | Yes |
| Illumination Mode | Smart IR |
| Defog | Electronic defog |
| Digital Zoom | 4× |
| Mirror | Yes |
| Privacy Masking | Off/On (8 areas, rectangle) |
| Certification |
| Certifications | CE-LVD: EN 62368-1; |
| CE-EMC: EN 55032; EN 55035; |
| FCC: 47 CFR FCC Part 15, Subpart B; |
| UL: UL62368-1 + CAN/CSA C22.2 No. 62368-1-14 |
| Port |
| Video Output | Video output choices of CVI/TVI/AHD/CVBS by one BNC port |
| Audio Input | One channel built-in MIC (-A) |
| Power |
| Power Supply | 12 VDC ± 10%; 24 VAC ± 25% |
| Power Consumption | Max 13.7W (12 VDC, IR on) |
| Environment |
| Operating Temperature | –30 °C to +60 °C (–22 °F to +140 °F) |
| Operating Humidity | <95% (RH), non-condensing |
| Storage Temperature | –30 °C to +60 °C (–22 °F to +140 °F) |
| Protection | IP67 |
| Structure |
| Casing Material | Metal |
| Product Dimensions | 90.4 mm × 90.1mm ×209.6 mm (3.56" × 3.55" × 8.25") |
| Net Weight | 0.58 kg (1.28 lb) |
| Gross Weight | 0.75 kg (1.65 lb) |
| Installation | Wall mount; ceiling mount; vertical pole mount |
