| Camera |
| Image Sensor | 4/3" CMOS |
| Effective Pixels | 3840(H)×2160(V), 8MP |
| Scanning System | Progressive |
| Electronic Shutter Speed | 1/3s~1/100,000s |
| Minimum Illumination | 0.001Lux/F1.2(Color,1/3s,30IRE) |
| 0.0005Lux/F0.95 (Color,1/3s,30IRE) |
| 0.003Lux/F0.95 (Color,1/30s,30IRE) |
| 0.0003Lux/F0.95 (B/W,1/3s,30IRE) |
| 0.002Lux/F0.95 (B/W,1/30s,30IRE) |
| S/N Ratio | More than 65dB |
| IR Distance | NA |
| IR On/Off Control | NA |
| IR LEDs | NA |
| Audio In | Built- in Mic |
| Lens |
| Lens Type | External |
| Mount Type | M43-mount |
| Focal Length | NA |
| Max Aperture | NA |
| Angle of View | NA |
| Focus Control | N/A |
| Close Focus Distance | NA |
| Pan / Tilt / Rotation |
| Pan/Tilt/Rotation | Pan: NA |
| Tilt: NA |
| Rotation: NA |
| Video |
| Resolution | 8MP (3840×2160) |
| Frame Rate | PAL:4K@12.5fps;4M@25fps |
| NTSC:4K@15fps;4M@30fps |
| Video Output | 1-channel HDMI video output & 1-channel BNC video output |
| Day/Night | Auto (Electronic) / Manual |
| OSD Menu | Multi-language |
| BLC Mode | BLC / HLC / WDR |
| WDR | 140dB |
| Gain Control | AGC |
| Noise Reduction | 2D/3D |
| White Balance | Auto / Manual |
| Smart IR | NA |
| Certifications |
| Certifications | CE (EN55032, EN55024, EN50130-4) |
| FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014) |
| UL (UL60950-1+CAN/CSA C22.2 No.60950-1) |
| Interface |
| Audio Interface | 1-channel audio in |
| Alarm I/O | 2.1 |
| Electrical |
| Power Supply | 12V DC ±25%/24V AC ±25% |
| Power Consumption | Max 6.4W (DC12V ) |
| Environmental |
| Operating Conditions | -30°C ~ +60°C (-22°F ~ +140°F) / Less than 90% RH |
| * Start up should be done at above -30°C (-22°F) |
| Storage Conditions | -30°C ~ +60°C (-22°F ~ +140°F) / Less than 90% RH |
| Ingress Protection & Vandal Resistance | NA |
| Construction |
| Casing | Aluminium |
| Dimensions | 144.5mm×82mm×73.7mm (5.69"×3.23"×2.90") |
| Net Weight | 0.62kg (1.36lb) |
| Gross Weight | 0.83kg (1.83lb) |
