| Camera |
| Image Sensor | 1/2.7 inch CMOS |
| Effective Pixels | 2592 (H) × 1944 (V), 5MP |
| Scanning System | Progressive |
| Electronic Shutter Speed | PAL: 1/25s–1/100000s |
| NTSC: 1/30s–1/100000s |
| S/N Ratio | >65dB |
| Minimum Illumination | 0.005Lux/F1.2, 0Lux White Light on |
| Fill Light (White Light) Distance | Distance up to 20 m (65.61 ft) |
| Fill Light On/Off Control | Auto; manual |
| Fill Light Number | 1 |
| Pan/Tilt/Rotation Range | Pan: 0°–360° |
| Tilt: 0°–78° |
| Rotation: 0°–360° |
| Lens |
| Lens Type | Fixed-focal |
| Mount Type | M12 |
| Focal Length | 2.8 mm; 3.6 mm |
| Max. Aperture | F1.2 |
| Field of View | 2.8 mm: 129° × 98° × 71° |
| (diagonal × horizontal × vertical) |
| 3.6 mm: 111° × 83° × 56° |
| (diagonal × horizontal × vertical) |
| Iris Type | Fixed iris |
| Close Focus Distance | 2.8 mm: 1.6 m (5.25 ft) |
| 3.6 mm: 2.1 m (6.89 ft) |
| DORI Distance | Lens | Detect | Observe | Recognize | Identify |
| 3.6 mm | 80.0 m (262.5 ft) | 32.0 m (105.0 ft) | 16.0 m (52.5 ft) | 8.0 m(26.2 ft) |
| Video |
| Frame Rate | CVI: |
| PAL: 5M@20fps, 4M@25fps, 1080P@25fps; |
| NTSC: 5M@20fps, 4M@30fps, 1080P@30fps |
| AHD: PAL: 5M@20fps, 4M@25fps; |
| NTSC: 5M@20fps, 4M@30fps |
| TVI: PAL: 5M@20fps, 4M@25fps; |
| NTSC: 5M@20fps, 4M@30fps |
| CVBS: PAL: 960H; |
| NTSC: 960H |
| Resolution | 5M (2592 × 1944); 4M (2560 × 1440); 1080P (1920 × 1080); 960H (704 × 576/704 × 480); |
| BLC | BLC/HLC/DWDR |
| WDR | DWDR |
| White Balance | Auto; manual |
| Gain Control | Auto; manual |
| Noise Reduction | 2D NR |
| Smart Light | Yes |
| Mirror | Off/On |
| Privacy Masking | Off/On (8 area, rectangle) |
| Certifications |
| Certifications | CE (EN55032, EN55024, EN50130-4,EN60950-1) |
| FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014) |
| UL (UL60950-1+CAN/CSA C22.2 No.60950-1) |
| Port |
| Video Output | Video output choices of CVI/TVI/AHD/CVBS by one BNC port |
| Audio Interface |
| Audio Input | Built-in mic (-A) |
| Power |
| Power Supply | 12V ±30% DC |
| Power Consumption | Max 3.0W (12V DC, White Light on) |
| Environment |
| Operating Temperature | -40°C to +60°C (-40°F to 140°F); <95% (non-condensation) |
| Storage Temperature | -40°C to +60°C (-40°F to 140°F); <95% (non-condensation) |
| Protection Grade | IP67 |
| Structure |
| Casing | Inner core: metal + plastic |
| Cover: plastic |
| Pedestal: plastic |
| Camera Dimensions | φ97 mm × 85.8 mm (φ3.82" × 3.38") |
| Net Weight | 0.22 Kg (0.49 lb) |
| Gross Weight | 0.28 Kg (0.62 lb) |
