Açıklama
Allied Telesis AT x230 18GP 10/100/100 PoE Switch
Özellikler
- Allied Ware Plus feature-rich operating system
- CLI and Web Interface
- Allied Telesis Management Framework™ (AMF)
- Ethernet Protection Switched Ring (EPSRing™)
- Power over Ethernet (PoE+)
- Active Fiber Monitoring
- Access Control Lists (ACL)
- Industry-leading Quality of Service (QoS)
- sFlow
- Network Access Control (NAC)
- Tri-Authentication
- Voice VLAN
- IPv6 management
- Energy Efficient Ethernet (EEE)
Teknik Özellikler
| Main Specifications |
| Product Description: |
| Allied Telesis AT x230-18GP - switch - 16 ports - managed - desktop, rack-mountable, wall-mountable |
| Device Type: |
| Switch - 16 ports - L2+ - managed |
| Enclosure Type: |
| Desktop, rack-mountable, wall-mountable 1U |
| Subtype: |
| Gigabit Ethernet |
| Ports: |
| 16 x 10/100/1000 (PoE+) + 2 x SFP |
| Power Over Ethernet (PoE): |
| PoE+ |
| PoE Budget: |
| 240 W |
| Performance |
| Switching capacity |
| 36 Gbps |
| Forwarding performance |
| 26.8 Mpps |
| MAC Address Table Size |
| 16K entries |
| Jumbo Frame Support |
| 10KB |
| Routing Protocol |
| CIDR |
| Remote Management Protocol |
| SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, SSH, CLI |
| Features |
| Flow control, full duplex capability, ARP support, VLAN support, IGMP snooping, Syslog support, port mirroring, DiffServ support, Weighted Round Robin (WRR) queuing, IPv6 support, SNTP support, sFlow, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree |
| Protocol (MSTP) support, DHCP snooping, Trivial File Transfer Protocol (TFTP) support, Access Control List (ACL) support, Quality of Service (QoS), MLD snooping, Dynamic ARP Inspection (DAI), Per-VLAN Spanning Tree Plus (PVST+), STP Root Guard, SNMP trap, DHCP client, |
| Energy Efficient Ethernet, Network Access Control (NAC), Strict Priority Queuing (SPQ), loop prevention, enviromental monitoring, packet storm protection, tagged VLAN, Ethernet Ring Protection Switching (ERPS), 1.5MB packet buffer, Storm Control |
| Compliant Standards |
| IEEE 802.2, IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ac, IEEE 802.1s, IEEE 802.1v, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az, |
| IEEE 802.1AX |
| Power |
| AC 120/230 V ( 50/60 Hz ) |
| Dimensions (WxDxH) |
| 13.4 in x 9.1 in x 1.7 in |
| Weight |
| 6.61 lbs |
| Manufacturer Warranty |
| Limited lifetime warranty |
| General |
| Device Type |
| Switch - 16 ports - L2+ - managed |
| Enclosure Type |
| Desktop, rack-mountable, wall-mountable - 1U |
| Subtype |
| Gigabit Ethernet |
| Ports |
| 16 x 10/100/1000 (PoE+) + 2 x SFP |
| Power Over Ethernet (PoE) |
| PoE+ |
| PoE Budget |
| 240 W |
| Performance |
| Switching capacity |
| 36 Gbps |
| Forwarding performance |
| 26.8 Mpps |
| MAC Address Table Size: |
| 16K entries |
| Jumbo Frame Support: |
| 10KB |
| Routing Protocol: |
| CIDR |
| Remote Management Protocol: |
| SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, SSH, CLI |
| Encryption Algorithm: |
| DES, Triple DES, RSA, MD5, SHA-1, TLS 1.0, SSL 3.0, SSL 2.0, PEAP, TTLS |
| Authentication Method: |
| Secure Shell (SSH), RADIUS, TACACS+, Secure Shell v.2 (SSH2), Extensible Authentication Protocol (EAP) |
| Features: |
| Flow control, full duplex capability, ARP support, VLAN support, IGMP snooping, Syslog support, port mirroring, DiffServ support, Weighted Round Robin (WRR) queuing, IPv6 support, SNTP support, sFlow, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree |
| Protocol (MSTP) support, DHCP snooping, Trivial File Transfer Protocol (TFTP) support, Access Control List (ACL) support, Quality of Service (QoS), MLD snooping, Dynamic ARP Inspection (DAI), Per-VLAN Spanning Tree Plus (PVST+), STP Root Guard, SNMP trap, DHCP client, |
| Energy Efficient Ethernet, Network Access Control (NAC), Strict Priority Queuing (SPQ), loop prevention, enviromental monitoring, packet storm protection, tagged VLAN, Ethernet Ring Protection Switching (ERPS), 1.5MB packet buffer, Storm Control |
| Compliant Standards: |
| IEEE 802.2, IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ac, IEEE 802.1s, IEEE 802.1v, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az, |
| IEEE 802.1AX |
| RAM: |
| 256 MB - DDR SDRAM |
| Flash Memory: |
| 64 MB |
| Expansion / Connectivity |
| Interfaces: |
| 16 x 1000Base-T - RJ-45 - 8 ports (PoE+) / 16 ports (PoE) |
| 1 x console - RJ-45 - management |
| 2 x - SFP - uplink |
| Expansion Slots: |
| 1 (total) / 1 (free) x SD Memory Card |
| Power |
| Power Device: |
| Internal power supply |
| Voltage Required: |
| AC 120/230 V ( 50/60 Hz ) |
| Miscellaneous |
| Cables Included: |
| 1 x console cable - 6.6 ft |
| Rack Mounting Kit: |
| Optional |
| Compliant Standards: |
| FCC Class A certified, UL, cUL, EN 61000-3-2, EN 61000-3-3, EN55024, EN55022 Class A, AS/NZS 60950-1, RoHS, UL 60950-1, EN 60950-1, EN 60825-1, CAN/CSA C22.2 No. 60950-1-03, VCCI Class A, China RoHS |
| Dimensions & Weight |
| Width: |
| 13.4 in |
| Depth: |
| 9.1 in |
| Height: |
| 1.7 in |
| Weight: |
| 6.61 lbs |
| Manufacturer Warranty |
| Service & Support: |
| Limited lifetime warranty |
| Service & Support Details: |
| Limited warranty - lifetime |
| Limited warranty - power supply and fans - 5 years |
| Environmental Parameters |
| Min Operating Temperature: |
| 32 °F |
| Max Operating Temperature: |
| 122 °F |
| Humidity Range Operating: |
| 5 - 90% (non-condensing) |
| Min Storage Temperature: |
| -13 °F |
| Max Storage Temperature: |
| 158 °F |
| Humidity Range Storage: |
| 5 - 95% (non-condensing) |
Allied Telesis AT x230 18GP 10/100/100 PoE Switch Pdf Dosyası1.79 MB
Teknik Kısa
PoE : PoE Plus
Port Hızı : 1 GBit
Yönetilebilirlik : Yönetilebilir Layer 2 Plus
Aktarım Port Sayısı : 2
Aktarım Türü : Gbit Fiber
Montaj Tipi : Rack Mount
Wall Mount
Desk Mount
PoE Port Sayısı :
16 Port
16 Port PoE Güç Bütçesi : 200-400 Watt
