| Camera |
| Image Sensor | 1/2.7 inch CMOS |
| Effective Pixels | 3840 (H)×2160 (V), 4K |
| Electronic Shutter Speed | PAL: 1/3s-1/100000s |
| NTSC: 1/4s-1/100000s |
| Minimum Illumination | 0.03Lux/F2.0, 30IRE, 0Lux IR on |
| IR Distance | Distance up to 80m (262.47ft) |
| IR On/Off Control | Auto/manual |
| IR LED Number | 2 |
| Pan/Tilt/Rotation Range | Pan: 0°–360° |
| Tilt: 0°–90° |
| Rotation: 0°–360° |
| Lens |
| Lens Type | Fixed-focal |
| Mount Type | M12 |
| Focal Length | 3.6mm; 6mm |
| Max. Aperture | F2.0 |
| Angle of View | 3.6mm: 104°×87°×47° (diagonal×horizontal×vertical) |
| 6mm: 62.4°×54.7°×31.3° (diagonal×horizontal×vertical) |
| Iris Type | Fixed iris |
| Close Focus Distance | 1.8m/3.6m (5.91ft/11.81ft) |
| DORI Distance | Lens | Detect | Observe | Recognize | Identify |
| 3.6mm | 107m (351ft) | 43m (141ft) | 21m (69ft) | 11m (36ft) |
| 6mm | 160m (525ft) | 64m (210ft) | 32m (105ft) | 16m (52ft) |
| Video |
| Video Frame Rate | CVI: 4K@15fps; 5M@20fps; 4M@25fps/30fps |
| CVBS: PAL/NTSC |
| AHD: 5M@20fps; 4M@25fps/30fps |
| TVI: 5M@20fps; 4M@25fps/30fps |
| Resolution | 4K (3840×2160); 5M (2592×1944); 4M (2560×1440); 960H (960× 576/960×480) |
| Day/Night | Auto switch by ICR |
| BLC | BLC/HLC/WDR |
| WDR | 120dB/WDR |
| White Balance | Auto; manual |
| Gain Control | Auto; manual |
| Noise Reduction | 2D&3D NR |
| Smart IR | Yes |
| Electronic Defog | Yes |
| Digital Zoom | 4X |
| Mirror | Off/On |
| Privacy Masking | Off/On (8 Area, Rectangle) |
| Certifications |
| Certifications | CE (EN55032, EN55024, EN50130-4) |
| FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014) |
| UL (UL60950-1+CAN/CSA C22.2 No.60950-1)" |
| Port |
| Video Port | Video output choices of CVI/TVI/AHD/CVBS by one BNC port |
| Power |
| Power Supply | 12V±30% DC |
| Power Consumption | Max 6.5W (12V DC, IR on) |
| Environment |
| Operating Temperature | -40°C to +60°C (-40°F to 140°F); <95%(non-condensation) |
| Storage Temperature | -40°C to +60°C (-40°F to 140°F); <95% |
| (non-condensation) |
| Protection Grade | IP67 |
| Structure |
| Casing | Metal front cover+plastic main body+plastic bracket |
| Dimensions | 241.8mm×90.4mm×90.4mm ( 9.52"×3.56"×3.56") |
| Net Weight | 600g (1.32lb) |
| Gross Weight | 760g (1.68lb) |
