Dahua HAC-HFW2501TU-Z-A-POC HDCVI Bullet Kamera
Özellikler
- The parameters and datasheets below can only be applied to 2501-POC-S2 series.
- In order to use the 5MP 16:9 HDCVI camera, the firmware of XVR must be upgraded to V4.001.0000001.0.R.200908 or later version.
- Max. 25 fps@5MP (16:9 video output)
- Starlight, 120 dB true WDR, 3D NR
- CVI/CVBS/AHD/TVI switchable
- Built-in mic
- 2.7 mm–13.5 mm motorized lens
- Max. IR length 80 m, Smart IR
- IP67, PoC (only CVI)/12V±30% DC
Teknik Özellikler
| Camera | |||||
| Image Sensor | 1/2.7" CMOS | ||||
| Max. Resolution | 2880 (H) × 1620 (V) | ||||
| Pixel | 5MP | ||||
| Scanning System | Progressive | ||||
| Electronic Shutter Speed | PAL: 1/3 s–1/100,000 s | ||||
| NTSC: 1/4 s–1/100,000 s | |||||
| S/N Ratio | > 65 dB | ||||
| Min. Illumination | 0.001 Lux/F1.6; 30IRE; 0 Lux IR on | ||||
| Illumination Distance | 80 m (262.5 ft) | ||||
| Illuminator On/Off Control | Auto/manual | ||||
| Illuminator Number | 4 (IR light) | ||||
| Pan/Tilt/Rotation Range | Pan: 0°–360° | ||||
| Tilt: 0°–90° | |||||
| Rotation: 0°–360° | |||||
| Lens | |||||
| Lens Type | Motorized vari-focal | ||||
| Auto Focus | Yes | ||||
| Mount Type | φ14 | ||||
| Focal Length | 2.7 mm–13.5 mm | ||||
| Max. Aperture | F1.6 | ||||
| Field of View | H: 31.4°–113° | ||||
| V: 17.6°–58° | |||||
| D: 36°–138° | |||||
| Iris Type | Fixed | ||||
| Close Focus Distance | 0.8 m (2.6 ft) | ||||
| DORI distance | Lens | Detect | Observe | Recognize | Identify |
| 2.7mm | 64.0 m(210.0 ft) | 25.6 m(84.0 ft) | 12.8 m(42.0 ft) | 6.4 m(21.0 ft) | |
| 13.5mm | 210.0 m(689.0 ft) | 84.0 m(275.6 ft) | 42.0 m(137.8 ft) | 21.0 m(68.9 ft) | |
| Video | |||||
| Frame Rate | CVI: | ||||
| PAL: 5M@25 fps; 4M@25 fps | |||||
| NTSC: 5M@25 fps; 4M@30 fps | |||||
| AHD: | |||||
| PAL: 4M@25 fps | |||||
| NTSC: 4M@30 fps | |||||
| TVI: | |||||
| PAL: 4M@25 fps | |||||
| NTSC: 4M@30 fps | |||||
| CVBS: | |||||
| PAL: 960H | |||||
| NTSC: 960H | |||||
| Resolution | 5M (2880 × 1620); 4M (2560 × 1440); 960H (960 × 576/960 × 480) | ||||
| Day/Night | Auto (ICR) | ||||
| BLC | BLC/HLC/WDR/HLC-Pro | ||||
| WDR | 120 dB | ||||
| White Balance | Auto/manual | ||||
| Gain Control | Auto/manual | ||||
| Noise Reduction | 3D NR | ||||
| Smart Illumination | Yes | ||||
| Digital Zoom | 4x | ||||
| Defog | Electronic defog | ||||
| Mirror | Yes | ||||
| Privacy Masking | Off/On (8 areas, rectangle) | ||||
| Certifications | |||||
| Certifications | CE (EN55032:2015, EN 61000-3-2:2014, EN 61000-3-3:2013, EN55024:2010+A1:2015, EN 55035:2017, EN50130-4:2011+A1:2014, EN 62368-1:2014+A11:2017) | ||||
| FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014) | |||||
| UL (UL60950-1+CAN/CSA C22.2 No.60950-1) | |||||
| Port | |||||
| Audio Interface | One channel built-in mic | ||||
| Video Output | Video output choices of CVI/TVI/AHD/CVBS by one BNC port | ||||
| Power | |||||
| Power Supply | POC (only CVI)/12V±30% DC | ||||
| Power Consumption | Max 8.2W (12V DC, IR on); PoC (AT) | ||||
| Environmental | |||||
| Operating Temperature | –30°C to +60°C (–22°F to +140°F); < 95% | ||||
| (non-condensation) | |||||
| Storage Temperature | –30°C to +60°C (–22°F to +140°F); < 95% | ||||
| (non-condensation) | |||||
| Protection Grade | IP67 | ||||
| Structure | |||||
| Casing | Metal throughout the whole casing | ||||
| Camera Dimensions | 244.1 mm × 90.4 mm × 90.4 mm | ||||
| (9.61" × 3.56" × 3.56") | |||||
| Net Weight | 0.80 kg (1.76 lb) | ||||
| Gross Weight | 1.06 kg (2.34 lb) | ||||
