Açıklama
Vivotek FD8371EV IP HD Dome Kamera
Özellikler
- 3-Megapixel CMOS Sensor
- 30 fps @ 2048x1536; 60fps @ 1920x1080
- Motorized, P-iris Lens & DC-iris
- Built-in IR Illuminators, Effective up to 20 Meters
- Smart IR Technology to Avoid Overexposure
- Smart Stream to Optimize Bandwidth Efficiency
- 3D Noise Reduction for Low-light Conditions
- -50°C ~ 50°C Wide Temperature Range for Extreme Weather Conditions
- Real-time H.264, MPEG-4, and MJPEG Compression (Triple Codec)
- Smart Focus System for Remote and Precise Focus Adjustment
- Two-way Audio
- Weather-proof IP66-rated and Vandal-proof IK10-rated Housing
- Built-in 802.3af Compliant PoE
- Built-in MicroSD/SDHC/SDXC Card Slot for On-board Storage
- Supreme Night Visibility
Teknik Özellikler
| Model | FD8371EV |
| System Information | |
| CPU | Multimedia SoC (System-on-Chip) |
| Flash | 256 MB |
| RAM | 512 MB |
| Camera Features | |
| Image Sensor | 1/2.8" Progressive CMOS |
| Maximum Resolution | 2048x1536 |
| Lens Type | Vari-focal, remote focus |
| Focal Length | f = 3 ~ 10 mm |
| Aperture | F1.3 ~ F2.5 |
| Auto-iris | P-iris / DC-iris (Reserved) |
| Field of View | 32° ~ 99° (Horizontal) |
| 24° ~ 72° (Vertical) | |
| 40° ~ 128° (Diagonal) | |
| Shutter Time | 1/5 sec. to 1/8,000 sec. |
| Physical Adjustment of Camera Angel | Pan: 348°, Tilt: 65°, Rotation: 350° |
| WDR Technology | WDR Enhanced |
| Day & Night | Removable IR-cut filter for day & night function |
| Smart IR Technology to Avoid Overexposure | |
| Minimum Illumination | 0.1 Lux @ F1.3 (Color) |
| 0.001 Lux @ F1.3 (B/W) | |
| Pan/tilt/zoom Functionalities | ePTZ: |
| 48x digital zoom (4x on IE plug-in,12x built in) | |
| IR Illuminators | Built-in IR illuminators, effective up to 20 meters |
| IR LED*4, with Smart IR Technology | |
| On-board Storage | MicroSD/SDHC/SDXC card slot |
| Video | |
| Compression | H.264, MJPEG |
| Maximum Frame Rate | H.264: |
| 30 fps at 2048x1536 | |
| 60 fps at 1920x1080 | |
| MJPEG: | |
| 30 fps at 2048x1536 | |
| 60 fps at 1920x1080 | |
| Maximum Streams | 4 simultaneous streams |
| S/N Ratio | 58 dB |
| Dynamic Range | 59 dB |
| Video Streaming | Adjustable resolution, quality and bitrate |
| Image Settings | Adjustable image size, quality and bit rate |
| Time stamp, text overlay, flip & mirror | |
| Configurable brightness, contrast, saturation, sharpness, white balance, exposure control, gain, backlight compensation, privacy masks, scheduled profile settings, audio detection, 3D noise reduction, smart stream, seamless recording, video rotation | |
| Audio | |
| Audio Capability | Two-way Audio (full duplex) |
| Compression | AAC, G.711, G.726 |
| Interface | External microphone input and output |
| Network | |
| Users | Live viewing for up to 10 clients |
| Protocols | IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP, 802.1X |
| Interface | 10Base-T / 100BaseTX Ethernet (RJ-45) |
| * It is highly recommended to use standard Cat. 5e & Cat. 6 cables which are compliant with the 3P/ETL standard. | |
| ONVIF | Supported, specification available at www.onvif.org |
| Intelligent Video | |
| Video Motion Detection | Triple-window video motion detection |
| Alarm and Event | |
| Alarm Triggers | Video motion detection, manual trigger, digital input, periodical trigger, system boot, recording notification, camera tampering detection, audio detection |
| Alarm Events | Event notification using digital output, HTTP, SMTP, FTP and NAS server |
| File upload via HTTP, SMTP, FTP and NAS server | |
| General | |
| Smart Focus System | Remote focal & focus control |
| Connectors | RJ-45 cable connector for Network/PoE connection |
| Audio input | |
| Audio output | |
| AC 24V power input/DC 12V power input | |
| Digital input*1 | |
| Digital output*1 | |
| Analog video output | |
| LED Indicator | System power and status indicator |
| Power Input | 24V AC |
| 12V DC | |
| IEEE 802.3af PoE Class 3 | |
| Power Consumption | Max. 28 W (DC 12V) |
| Max. 34 W (AC 24V) | |
| Max. 12.95 W (PoE) | |
| Dimensions | Ø: 173 mm x 115 mm |
| Weight | Net: 1,240g |
| Casing | Weather-proof IP66-rated housing |
| Vandal-proof IK10-rated housing | |
| Safety Certifications | CE, LVD, FCC Class A, VCCI, C-Tick, UL, KCC |
| Operating Temperature | PoE |
| Working Temperature: -10°C ~ 50°C (14°F ~ 122°F) | |
| Cold Startup Temperature: -10°C (14°F) | |
| DC12V/AC24V | |
| Working Temperature: -50°C ~ 50°C (-58°F ~ 122°F) | |
| Cold Startup Temperature: -40°C (-40°F) | |
| Warranty | 24 months |
| System Requirements | |
| Operating System | Microsoft Windows 7/Vista/XP/2000 |
| Web Browser | Mozilla Firefox 7~10 (Streaming only) |
| Internet Explorer 7.x or 8.x | |
| Other Players | VLC: 1.1.11 or above |
| QuickTime: 7 or above | |
| Included Accessories | |
| CD | User's manual, quick installation guide, Installation Wizard 2, ST7501 32-channel recording software |
| Others | Quick installation guide, warranty card, alignment sticker, mounting plate, L-type hex key wrench, desiccant bag, DC connector, screws, hex nut, double-sided Tape, AV cable, waterproof connector, bushing, software CD |
Video
Teknik Kısa
Çözünürlük : 3MP
Ses : Var
Irled : Var
Depolama : Var
