Vivotek FD8373 EHV IP HD Dome Kamera

Özellikler

3-Megapixel CMOS Sensor
20 fps @ 2048x1536
Motorized, P-iris Lens
Smart IR Technology to Avoid Overexposure
Built-in IR Illuminators, Effective up to 20 Meters
Smart Stream
3D Noise Reduction
Built-in MicroSD/SDHC/SDXC Card Slot for On-board Storage
WDR Pro for Unparalleled Visibility in Extremely Bright and Dark Environments
Smart Focus System for Remote and Precise Focus Adjustment
Two-way Audio
Weather-proof IP66-rated Housing
Vandal-proof IK10-rated Housing

Teknik Özellikler

System Information
CPU	Multimedia SoC (System-on-Chip)
Flash	128 MB
RAM	256 MB
Camera Features
Image sensor	1/3" Progressive CMOS
Maximum Resolution	2048x1536 (3MP)
Lens Type	Vari-focal, remote focus
Focal Length	f = 2.8 ~ 12 mm
Aperture	F1.8 ~ F2.85
Auto-iris	P-iris
Field of View	29.7° ~ 82.6° (horizontal)
	22.4° ~ 61.9° (vertical)
	37.6° ~ 108.7° (diagonal)
Shutter Time	1/5 sec. to 1/32,000 sec.
WDR Technology	WDR Pro
Day & Night	Removable IR-cut filter for day & night function
Day & Night	Smart IR Technology to Avoid Overexposure
Minimum Illumination	0.33 Lux @ F1.8 (Color)
Minimum Illumination	0.001 Lux @ F1.8 (B/W)
Pan / Tilt / Zoom	ePTZ
Pan / Tilt / Zoom	48x digital zoom ( 4x on IE plug-in, 12x built-in )
IR Illuminators	Built-in IR illuminators, effective up to 20 meters
IR Illuminators	IR LED*4 with Smart IR Technology
On-board Storage	MicroSD/SDHC/SDXC card slot
Video
Compression	H.264, MJPEG
Maximum Frame Rate	H.264:
	20 fps at 2048x1536
	30 fps at 1920x1080
	MJPEG:
	20 fps at 2048x1536
	30 fps at 1920x1080
Maximum Streams	3 simultaneous streams
S/N Ratio	Above 62 dB
Dynamic Range	100 dB
Video Streaming	Adjustable resolution, quality and bit rate
Image Settings	Adjustable image size, quality and bit rate
	Time stamp, text overlay, flip & mirror
	Configurable brightness, contrast, saturation, sharpness, white balance, exposure control, gain, backlight compensation, privacy masks, Scheduled profile settings
	3D Noise Reduction, Smart Stream
	Seamless recording, new text on video, SD recording 1HR
Audio
Audio Capability	Audio input/output (full duplex)
Compression	AAC, G.711, G.726
Interface	External microphone input and Output
Network
Users	Live viewing for up to 10 clients
Protocols	IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP, 802.1X
Interface	10Base-T / 100BaseTX Ethernet (RJ-45)
Interface	* It is highly recommended to use standard Cat. 5e & Cat. 6 cables which are compliant with the 3P/ETL standard.
ONVIF	Supported, specification available at www.onvif.org
Intelligent Video
Video Motion Detection	Triple-window video motion detection
Alarm and Event
Alarm Triggers	Video motion detection, manual trigger, digital input, periodical trigger, system boot, recording notification, camera tampering detection
Alarm Events	Event notification using HTTP, SMTP, FTP and NAS server
Alarm Events	File upload via HTTP, SMTP, FTP and NAS server
General
Smart Focus System	Remote focus
Connectors	RJ-45 for Network / PoE connection
	Audio input
	Audio output
	AC 24V power input
	DC 12V power input
	Digital iutput*1
	Digital output*1
LED Indicator	System power and status indicator
Power input	DC 12V
	AC 24V
	IEEE 802.3af PoE Class 3
Power consumption	DC: Max.25.2 W (Heater on), 11 W (Heater off)
	AC: Max. 26.25 W (Heater on), 12.5 W (Heater off)
	PoE: Max. 11 W
Dimensions	Ø: 173 mm x 115 mm
Weight	Net: 1,240 g
Casing	Weather-proof IP66-rated housing
Casing	Vandal-proof IK10-rated metal housing
Safety Certifications	CE, C-Tick, FCC Class A, LVD, UL, VCCI
Operating Temperature	Starting Temperature: -40°C ~ 50°C ( PoE: -10°C ~ 50°C )
Operating Temperature	Working Temperature: -50°C ~ 50°C ( PoE: -20°C ~ 50°C )
Warranty	36 Months
System Requirements
Operating System	Microsoft Windows 7 / Vista / XP / 2000
Browser	Mozilla Firefox 7~10 ( Streaming only )
Browser	Internet Explorer 7 / 8 / 9 / 10
Other Players	VLC: 1.1.11 or above
Other Players	QuickTime: 7 or above
