Dahua PSDW81642M-A180-D440-S3 Panoramik IP PTZ Kamera

Özellikler

Panoramic network camera: Four 1/1.8" 4 Megapixel progressive CMOS PTZ camera: One 1/1.8" 4 Megapixel progressive CMOS.
180-degree panoramic view.
Smart H265+/H264+ encoding.
WDR, 3D NR, HLC, BLC, applicable to various monitoring scenes.
Illumination distance up to 400 m.
40x optical zoom.
Smart tracking. GPS/BDS positioning.
Tripwire; intrusion; parking detection.
AR panorama technology; various AR tags can be overlaid.

Teknik Özellikler

Camera
Image Sensor	Panoramic network camera: 1/1.8"4 Megapixel progressive CMOS
	PTZ camera: 1/1.8"4 Megapixel progressive CMOS
Pixel	Panoramic network camera : 16 MP
	PTZ camera: 4 MP
Max. Resolution	5520 (H) × 2700 (V)
ROM	Panoramic network camera: 8 GB
	PTZ camera: 8 GB
RAM	Panoramic network camera: 4 GB
	PTZ camera: 2 GB
Scanning System	Progressive
Electronic Shutter Speed	Auto/Manual 1/3 s–1/100,000 s
Min. Illumination	Panoramic network camera:
	0.0005 lux@F1.0 (Color,30 IRE)
	0.0002 lux@F1.0 (B/W,30 IRE)
	PTZ camera:
	0.001 lux@F1.4 (Color,30 IRE)
	0.0005 lux @F1.4(B/W,30 IRE); 0 lux (Illuminator on)
S/N Ratio	>56 dB
Illumination Distance	Panoramic network camera:NA
	PTZ camera: ≥ 400 m (1312.34 ft)
Illuminator On/Off Control	Auto;Manual;Zoomprio
Illuminator Number	7 (IR LED)
Built-in Battery	Panoramic network camera: Horizontal welding/lithium battery/3 V
	PTZ camera: Horizontal welding/lithium battery/3 V
Lens
Lens Type	Panoramic network camera : Fixed-focal
	PTZ camera: Vari-focal
Lens Mount	Panoramic network camera : M16
	PTZ camera: Module
Focal Length	Panoramic network camera : 2.8 mm
	PTZ camera: 5.5 mm–220 mm
Max. Aperture	Panoramic network camera : F1.0
	PTZ camera: F1.4
Field of View	Panoramic network camera: H: 180°; V: 111°
	PTZ camera: H: 2.2°–61.8°; V: 1.3°–36.3°; D: 2.4°–69.2°
Iris Control	Panoramic network camera: Fixed
	PTZ camera: Auto
Iris Control Type	Panoramic network camera: NA
	PTZ camera: P-iris
Close Focus Distance	Panoramic network camera: 1.4 m (4.59 ft)
	PTZ camera: 0.5 m–2 m (1.64 ft–6.56 ft) (T to W)
DORI Distance	Lens	Detect	Observe	Recognize	Identify
	Panoramic network camera	57.9 m (189.96 ft)	23.2 m (76.11 ft)	11.6 m (38.06 ft)	5.8 m (19.03 ft)
	PTZ camera	3030 m (9940.94 ft)	1204 m (3950.13 ft)	606 m(1988.19 ft)	303 m (994.10 ft)
PTZ
Pan/Tilt Range	Pan: 0° to 360° endless
	Tilt: –11° to 90°, auto flip 180°
Manual Control Speed	Pan: 240°/s
	Tilt: 100°/s
Telephoto Speed Limit	Yes
Positioning Accuracy	Pan: 0.05°
	Tilt: 0.05°
Positioning Accuracy Automatic Calibration	Yes
Remote Lens Reset	Yes
Remote PTZ Reset	Yes
Preset	300
Tour	8 (up to 32 presets per tour)
Pattern	5
Scan	5
Power-off Memory	Yes
Idle Motion	Preset; Pattern; Tour; Scan
Scheduled Task	Preset; Pattern; Tour; Scan
3D Positioning	Yes
PTZ Limit	Yes
Position Display	Yes
Information Display	Yes
Time Display	Yes
PTZ Restart	Yes
Artifical Intelligence
IVS (Perimeter Protection)	Tripwire; intrusion; parking detection
Video
Video Compression	H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream)
Smart Codec	Smart H.264+;
	Smart H.265+
Video Frame Rate	Panoramic network camera :
	Main stream: 5520 × 2700@(1–25 fps)
	sub stream: 1920 × 940@(1–25 fps)
	third stream: 4096 × 2064@(1–25 fps)
	PTZ camera:
	Main stream: 2560 × 1440@(1–25 fps)
	sub stream: 704 × 576@(1–25 fps)
	third stream: 1920 × 1080@(1–25 fps)
Stream Capability	3 streams
Resolution	Panoramic network camera:
	Main stream: 5520 × 2700; 4600 × 2252; 3840 × 1880; 2880 × 1408
	sub stream: 1920 × 940; 1280 × 620; 1024 × 496
	third stream: 4096 × 2064; 2560 × 1252; 1366 × 668
	PTZ camera:
	Main stream: 2560 × 1440; 1920 × 1080; 1280 × 960; 1280 × 720
	sub stream: 704 × 576; 640 × 480; 352 × 288
	third stream: 1920 × 1080; 1280 × 960; 1280 × 720
Bit Rate Control	CBR/VBR
Video Bit Rate	Panoramic network camera:
	H.264: 96 kbps–20736 kbps;
	H.265: 38 kbps–12544 kbps;
	PTZ camera:
	H.264: 512 kbps–13056 kbps
	H.265: 204 kbps–7936 kbps
BLC	Yes
HLC	Yes
WDR	Panoramic network camera: 120 dB
	PTZ camera: 120 dB
Scene Self-adaptation (SSA)	Yes
White Balance	Auto; natural; street lamp; outdoor; manual; regional custom
Gain Control	Manual; Auto
Noise Reduction	3D NR
Motion Detection	OFF/ON (4 areas, rectangular)
Default Bit Rate with Default Resolution	Panoramic network camera: 6144 kbps (5520 × 2700)
	PTZ camera: 6144 kbps (2560 × 1440)
Region of Interest (RoI)	Panoramic network camera : Yes (4 areas)
	PTZ camera: Yes (8 areas)
Image Stabilization	Panoramic network camera: NA
	PTZ camera: Electronic Image Stabilization (EIS)
Defog	Panoramic network camera: NA
	PTZ camera: Optical defog
Image Flip	Panoramic network camera: NA
	PTZ camera: Yes
Privacy Masking	Panoramic network camera : 4 areas
	PTZ camera: 24 areas (8 for each preset)
Language	English; Italian; Spanish; Russian; French; German; Portuguese; Polish; Korean; Persian; Czech; Dutch; Arabic; European Spanish
Certifications
Certifications	CE-LVD: EN62368-1;
	CE-EMC: EN55032; EN55035; EN61000-3-2; EN61000-3-3; EN50130-4;
	FCC: Part 15; Subpart B;
	UL: UL62368-1
Audio
Audio Port	Yes
Audio Compression	PCM; G.711a; G.711Mu; G.726; G.723; G.711a by default
Audio Sampling	8 kHz; 16 kHz; 32 kHz; 48 kHz; 64 kHz
Port
RS-485	1 (baud rate range:1200 bps–115200 bps)
Optical Module Specification	SFP optical module, single mode, single fiber 20 KmTX-1310 nm/RX-1550 nm
Optical Fiber	FC
Optical Fiber Module Type	Gigabit SFP optical module, single mode, single fiber TX-1550 nm/RX-1310 nm
Audio Input	2 channels (terminal)
Audio Output	2 channels (terminal)
Alarm Input	7 channels in: 5mA 3V–5V DC
Alarm Output	3 channels out: 1,000mA 30V DC/500mA 50V AC
Analog Output	1 channel (CVBS output: BNC)
Network
Network Port	RJ-45 (10/100/1000 Base-T)
SDK and API	Yes
Network Protocol	IPv4; IPv6; HTTP;TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP
Cyber Security	Video encryption;Firmware encryption;Configuration encryption;Digest;WSSE;Account lockout;Security logs;IP/MAC filtering;Generation and importing of X.509 certification;syslog;HTTPS;802.1x;Trusted boot;Trusted execution;Trusted upgrade
Interoperability	ONVIF (Profile S/Profile G/Profile T); CGI; P2P
User/Host	20 (Total bandwidth: 400 M)
Storage	FTP;SFTP; Micro SD card (support max. 512 GB); NAS
Browser	IE: IE9, IE10 and IE11
	Chrome
	Firefox
Management Software	DSS
Power
Operating Voltage	36 VDC (±50%)
Power Supply	36 VDC
Power Consumption	Basic: 59 W (36 VDC)
	Max. (Basic power consumption + WDR + intelligence on + IR on + PTZ operation ): 99 W (36 VDC)
ePoE	No
Environment
Operating Temperature	–40 °C to +70 °C (–40 °F to +158 °F)
Operating Humidity	≤95%
Storage Temperature	–40 °C to +70 °C (–40 °F to +158 °F)
Protection	IP66
Structure
Casing Material	Metal + plastic
Product Dimensions	Φ383 mm × 462 mm (15.08"× Φ18.19")
Packaging Dimensions	500 mm × 500 mm × 658 mm (19.69" × 19.69" × 25.91") (L × W × H)
Net Weight	14.4 kg (31.75 lb)
Gross Weight	20.3 kg (44.75 lb)
Installation	Wall mount; ceiling mount; pole mount
Power Adapter	Included
Lens	Standard
Power Output	12 VDC power output, max. current 165 mA
Others
Position	GPS/BDS
Calibration	Manual/Auto
